SCHIND CMF01 Marble and Granite Chamfering Machine
Product Code: CMF01
Brand: SCHIND
Category: Machine , Marble, Natural Stone and Granite Machines
Origin: Turkey
Minimum Order: 1 Pc
Voltage: 380V

PRODUCT DESCRIPTION

  • Our surface polishing marble granite chamfering machine provides series and standard production.
  • Our fully automatic polishing machine is easy to use and maintain, and it chamfers from the bottom.
  • Our machine is controlled by front panel and all heads are working independently of each other.
  • The polishing heads automatically work and come out just after the entrance of the stone till finishing the relevant area, then automatically turns off and goes back.
  • Heads can be disabled according to the process.
  • The polished part of the marble must be placed on the production belt.
  • Conveyor belt movement is electronic speed controlled and width is 450mm...
  • Our machine is produced as 6+2,  8+2,  10+2,  12+2,  14+2 standard according to the sort of natural stone.
  • Our 12+2 machine has 1 caliber, 5 bottom chamfer, 6 side chamfer, 1 deburring and 1 drip saw.
  • The machine can process minimum 70/80 mm and up to 1500 mm with a bottom supported compasses mechanism.
  • The engine section of the machine is completely protected from water by internal and external protective parts.
  • The protective panels are opened and closed with the help of shock absorbers for lubrication channels maintenance and abrasive replacement.
  • Felt is used to be resistant of heat and abrasion to protect the head bearings behind the abrasive.
  • If the customer wants our machine can be integrated into the herringbone diamond.

PARTS and TECHNICAL SPECIFICATIONS 10+2 HEAD 12+2 HEAD 14+2 HEAD 16+2 HEAD
Polishing Motor Power 5 Pcs 1.5 kw 6 Pcs 1.5 kw 7 Pcs 1.5 kw 8 Pcs 1.5 kw
Chamfering Motor Power 4 Pcs 1.5 kw 5 Pcs 1.5 kw 6 Pcs 1.5 kw 7 Pcs 1.5 kw
Chamfer Caliber Motor Power 1 Pc 2,2 kw 1 Pc 2,2 kw 1 Pc 2,2 kw 1 Pc 2,2 kw
Burr Chamfer Motor Power 1 Pc 1,5 kw 1 Pc 1,5 kw 1 Pc 1,5 kw 1 Pc 1,5 kw
Dropper Saw Motor Power 1 Pc 2,2 kw 1 Pc 2,2 kw 1 Pc 2,2 kw 1 Pc 2,2 kw
Upper Pressure Motor Power 0,75 kw 0,75 kw 0,75 kw 0,75 kw
Band Reducer Motor Power 1,5 kw 1,5 kw 1,5 kw 1,5 kw
Total Electric Motor Power 21,00 kw 25,50 kw 29,50 kw 34,50 kw
Min. Working Width 70 mm 70 mm 70 mm 70 mm
Working Thickness 10 - 40 mm 10 - 40 mm 10 - 40 mm 10 - 40 mm
Band Speed 0 - 350 cm/sec 0 - 350 cm/sec 0 - 350 cm/sec 0 - 350 cm/sec
Length / Width / Height 7100 x 1700 x 2100 mm 7500 x 1700 x 2100 mm 8100 x 1700 x 2100 mm 8500 x 1700 x 2100 mm
Water Required 32 lt/sec 35 lt/sec 40 lt/sec 45 lt/sec
Saw Disc Diameter Q250 mm Q250 mm Q250 mm Q250 mm
Opening Table Width 1400 mm 1400 mm 1400 mm 1400 mm
Pneumatic Pressure 1-3 bar 1-3 bar 1-3 bar 1-3 bar
